DYR101 premium barcode resin ribbon is a high performance flat-head resin ribbon which expands the boundaries of traditional resin formulations, in terms of print speed and image sensitivity. DYR101 is capable of high speed printing, up to 10 ips, allowing significant improvements to labeling productivity and the use in high speed print/apply applications. The low energy characteristics of this ribbon allow users to reduce their printhead heat levels, therefore extending the life and reducing the costs of printhead ownership. The low energy characteristic of the DYR101 is ideally suited for the rapidly growing desktop printing market, where print head energy management can be more limited. The increased image sensitivity of the DYR101 provides outstanding print quality onto a wide variety of materials, including the newer value-prices films, therefore providing a lower cost of ownership model for the end-user. DYR101 provides dark, crisp printed images and our proprietary anti-statics back coating formulation dissipates static levels and works to extend the life of your valuable printheads.

SKU DYR101

Color Black

Total Thickness 6.0 ± 0.5 µm

Ink Thickness 1.2 ± 0.2 µm

Electrostatic ≤ 0.15 Kv

Optical Density ≥ 1.8 D

Glossiness ≥ 50 Gs

Ink Melt Point 79 °C

Storage Condition

Use within 12 months recommended

Keep away from UV and direct sunlight

Temperature 5-35°C (40-95°F)

Humidity 20-80%

(Remarks:The information on this data sheet was obatined in our labratories. Measured values may vary slightly when tested in a different environment. Informaiton contained within this document is subject to change without notification.)
