Color Wax Ribbon Red Wax DYW-104R

Color Wax Ribbon  Red Wax DYW-R101

Red PMS 1787C

Based on Dingyi Tech's proven wax technology, these quality ribbons can provide excellent print clarity

and high smudge resistance. Printhead protection backcoat technology.

Products Features:

Hight-density, high-speed,

Printhead protection,

Smudge resistance.


PDF Download
Send Inquiry

Color Wax Ribbon  Red Wax DYW-R101

Based on Dingyi tech’s proven wax technology, these quality ribbons expand your color possibilities while providing excellent print clarity and high smudge resistance when black just isn’t enough. DYW-R101 /DYW-R102 /DYW-R103 is also specially formulated with Dingyi Tech’s backcoat technology for printhead protection.


Applications

Recommand Substrates:

Paper ：

Coated Paper , Coated tag
Uncoated paper, Coated paper

Economy Synthetics:

PE, Polyolefin, PP,  Synthetic Paper.

Speciality Materials:

BOPP.

Recommand Application:

Inventory and Logistics , Outdoor


Specification

Color wax ribbon Technical Specifications

Ribbon Properties:

Ink : Wax.

Ink Color: Red.

Film Thickness:4.5±0.4μm.

Ink Thickness:1.3±0.4μm.

Total Thickness:5.8±0.8μm.

Ink Melting Point:78℃.

Temperature：5-35℃

Humidity：20-80%

Validity period：12months


Resistance Test:

Smudge Resistance

Scratch Resistance




(Remarks:The information on this data sheet was obatined in our labratories. Measured values may vary slightly when tested in a different environment. Informaiton contained within this document is subject to change without notification.)

Qualifications

The product is backed by the following certifications to ensure the quality and workmanship meet and exceed the industry standards.
