DYW101 eco-wax barcode ribbon offers our most economical wax thermal transfer printing solution while providing consistent performance on a wide variety of materials. Designed for barcode label and tag printing in the mainstream “sweet-spot” of 4–8 inches per second, the DYW101 provides high optical density, moderate image durability, and allows printing at low print head energy heat settings on all popular thermal transfer printers. DYW101 eco-wax is a “plug and play” formulation which can be dropped in at the same printer settings as most standard wax ribbons. DYW101 is a highly versatile ribbon which provides reliable printing performance on coated and uncoated labels and tags, and vellum materials found in today’s global world of thermal transfer materials. Ideal for competitively priced applications such as shipping, product identification, distribution, logistics and retail. Our proprietary anti-static back coating formulation dissipates static electricity and works to protect and extend the life of your valuable printhead.

Manufacturer Direct - As the only thermal transfer ribbon manufacturer that equipped with the vertical integration capability of PET base film, IMP offers a full line of "drop in replacement" thermal transfer barcode ribbon and hot stamp coding foil ribbon solutions at significant cost savings.

• SKU DYW101
• Color Black
• Total Thickness 7.1 ± 0.3 µm
• Ink Thickness 2.8 ± 0.2 µm
• Electrostatic ≤ 0.06 Kv
• Optical Density ≥ 1.82 D
• Ink Melt Point 68 °C
•

• Storage Condition
• Use within 12 months recommended
• Keep away from UV and direct  sunlight
• Temperature      5-35°C (40- 95°F)
• Humidity     20-80%

(Remarks:The information on this data sheet was obatined in our labratories. Measured values may vary slightly when tested in a different environment. Informaiton contained within this document is subject to change without notification.)
